Yash Fittings, based in Mumbai, India, is a premier manufacturer and exporter of high-performance piping fittings, providing dependable and long-lasting solutions for mission-critical industrial processes. Among its high-end products are Stainless Steel 904L Pipe Fittings, an austenitic stainless steel alloy famous for its excellent corrosion resistance, especially in aggressive environments with sulfuric, phosphoric, and acetic acids. Grade 904L is alloyed with significant proportions of chromium, nickel, molybdenum, and copper, giving them better pitting and stress corrosion cracking resistance, thus ideally suited for application in highly corrosive situations.
| 904L Pipe Fittings Specifications | ASTM A403/ ASME SA403 |
|---|---|
| 904L SS Pipe Fittings size | 904L Seamless Butt Weld Fittings : 1/2″ – 10″ 904L Welded Butt Weld Fittings : 1/2″ – 48″ |
| SS 904L Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Stainless Steel 904L Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| 904L Buttweld Pipe FittingsType | DN15-DN1200 |
| ASTM A403 904L Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM A403 Grade WP904L Pipe Fitting |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM A403 WP 904L Buttweld Fitting |
| ASTM A403 WP904L Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| 904L Stainless Steel Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SA 403 WP904L Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | SS UNS N08904, N08904 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
| We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Stainless Steel 904L Pipe Fittings have superior chemical, mechanical, and physical properties. Chemically, they consist of chromium (19–23%), nickel (23–28%), molybdenum (4–5%), and copper (1–2%), which give them excellent chemical resistance against acidic and chloride-rich environments. Mechanically, they provide tensile strength of approximately 490 MPa and yield strength of approximately 220 MPa, with excellent ductility and toughness. Physically, density is approximately 8.0 g/cm³, and they are stable and resistant to corrosion even at temperatures as high as 450°C and hence best suitable for extreme process conditions.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
| SS 904L | 0.020 max | 2.00 max | 1.00 max | 0.040 max | 0.030 max | 19.00 – 23.00 | 4.00 – 5.00 max | 23.00 – 28.00 | 1.00 – 2.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
Yash Fittings one of the largest suppliers of Stainless Steel 904L Pipe Fittings in Mumbai, India. We specialize in providing a wide range of high-quality, durable fittings for various industrial applications. Our inventory includes elbows, tees, reducers, couplings, and other essential fittings designed to offer exceptional corrosion resistance and strength. Stainless Steel 904L is known for its cost-effectiveness and excellent mechanical properties, making it ideal for industries such as construction, chemical processing, and food processing. With a commitment to customer satisfaction, timely delivery, and competitive pricing, we are the trusted choice for Stainless Steel 904L Pipe Fittings in the India.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 904L Pipe Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| Product range and theoretical weights (kg) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
SS 904L Pipe Fittings offer outstanding advantages, including exceptional resistance to corrosion, pitting, and stress corrosion cracking, particularly in acidic and chloride-rich environments. The high nickel and molybdenum content ensures excellent durability even in harsh conditions. These fittings maintain structural integrity at high temperatures and under thermal cycling. With low carbon content, they prevent carbide precipitation, making them ideal for welding applications. Their superior strength, ease of fabrication, and resistance to aggressive chemicals make them ideal for industries like chemical processing, pharmaceuticals, and marine applications.
Yes, custom sizes are available for Stainless Steel 904L Pipe Fittings to meet specific requirements. We offer tailored solutions to ensure precise fit and performance for various applications. For more information, please contact us at sales@yashfittings.com
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Stainless Steel 904L Pipe Fittings are extensively utilized in chemical processing, petrochemical, marine, pharmaceutical, and pulp and paper industries because of their superior resistance to aggressive environments and strong acids. These fittings are best suited for heat exchangers, condenser tubes, acid storage tanks, and seawater cooling systems. Their non-magnetic properties, high purity, and crevice and pitting corrosion resistance properties qualify them for corrosive and clean environments and provide reliable performance in high-pressure and critical applications.
