Stainless Steel 304L Pipe Fittings

Yash Fittings is a prominent manufacturer and supplier of first-class pipe fittings, offering extensive industrial applications. Its most sought-after products include Stainless Steel 304L pipe fittings due to their superior corrosion resistance and excellent durability. This grade, which is low-carbon content stainless steel of the 304 type, is suitable for applications involving welded structures, as it has better weldability and less carbide precipitation. Yash Fittings offers 304L fittings that are made to the highest industry standards, ensuring performance and reliability in various applications.

Stainless Steel 304L Pipe Fittings Price List in Mumbai, Stainless Steel DIN 1.4301 Pipes Fittings Supplier in Mumbai, UNS S30403 Stainless Steel Pipe Fittings Dealer in West Mumbai, ANSI B16.9 Welded Pipe Fittings Supplier in West Mumbai, ASME B16.49 90 Deg. Elbow Exporter in Mumbai, Stainless Steel 304L Swage Nipple Size Chart, Stainless Steel DIN 1.4301 Long Radius Bend Price in Mumbai, Stainless Steel 304L Equal Cross Thickness, Stainless Steel 304L 45° Eccentric Reducer Supplier in India, ANSI B16.9 90 Deg Elbow Stockist in Mumbai, Stainless Steel 304L End Pipe Cap Exporter in India

Stainless Steel 304L Pipe Fittings Specification

Specifications	:	ASTM A182 ASME SA 182
Tube Size	:	1/16”OD to 2”OD, 2mm OD to 50mm OD
Thread	:	NPT, BSP, BSPT, UNF, ISO, SAE etc.
Pressure Rating	:	6000PSI for Stainless Steel, 300/1000/3000PSI for Brass

Stainless Steel 304L pipe fittings are well-known for their outstanding chemical, mechanical, and physical properties, rendering them extremely versatile for numerous industrial applications. They are chemically composed of high chromium content (18-20%) and nickel content (8-12%), offering superior resistance to corrosion, oxidation, and rust even under extreme conditions. Mechanically, 304L is strong and tough, possessing a yield strength of approximately 205 MPa and tensile strength up to 515 MPa, making it durable in stress. Physically, it possesses high thermal conductivity and low magnetic permeability and is thus ideal for use at high temperatures. Its low carbon content further improves its weldability and reduces the carbide precipitation risk on welding.

Stainless Steel 304L Pipe Fittings Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	N
SS 304L	0.035 max	2 max	1.0 max	0.045 max	0.030 max	18 – 20	–	8 – 13	–

Stainless Steel 304L Pipe Fittings Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.0 g/cm3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

Stainless Steel UNS S30403 TEE Fittings Supplier in Mumbai, Stainless Steel 304L Expansion joint Weight Chart, UNS S30403 Stainless Steel 45 Degree Elbow Exporter in Mumbai, Stainless Steel 304L Reducers Manufacturer in West Mumbai, Stainless Steel 304L Swage Nipple Price List in India, Stainless Steel UNS S30403 Cross Fittings Sizes in mm, Stainless Steel 1.4301 Four Way Fittings Distributor in Mumbai, DIN 1.4301 Stainless Steel Wye Reducing in Mumbai, Stainless Steel 304L Barrel Nipples Distributor in India

Largest Stainless Steel 304L Pipe Fittings Supplier in Mumbai, India

Yash Fittings one of the largest suppliers of Stainless Steel 304L Pipe Fittings in Mumbai, India. We specialize in providing a wide range of high-quality, durable fittings for various industrial applications. Our inventory includes elbows, tees, reducers, couplings, and other essential fittings designed to offer exceptional corrosion resistance and strength. Stainless Steel 304L is known for its cost-effectiveness and excellent mechanical properties, making it ideal for industries such as construction, chemical processing, and food processing. With a commitment to customer satisfaction, timely delivery, and competitive pricing, we are the trusted choice for Stainless Steel 304L Pipe Fittings in the India.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Why Choose Stainless Steel 304L Pipe Fittings From Yash Fittings?

Stainless Steel 304L Pipe Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Stainless Steel 304L Pipe Fittings Dimensions :

Nominal Pipe Size	All Fittings	All Fittings	All Fittings	Elbows/ Tees	180° Return Bends	180° Return Bends	180 Deg Return Bends	Reducers	Caps
NPS	O.D. at Bevel (1), (2)	I.D. at End (1), (3), (4)	Wall Thickness (3)	Centre-to-End Dimension A,B,C,M	Centre-to-Centre O	Back-to-Face K	Alignment of Ends U	Overall Length H	Overall Length E
½ to 2½	0.06 -0.03	0.03	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
3 to 3 ½	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
4	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
5 to 8	0.09 -0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.25
10 to 18	0.16 -0.12	0.12	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
20 to 24	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
26 to 30	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.12	…	…	…	0.19	0.38
32 to 48	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.19	…	…	…	0.19	0.38

Stainless Steel 304L Pipe Fittings Equivalent Grade

Grade	UNS No	Old British		Euronorm		Swedish SS	Japanese JIS
		BS	En	No	Name
304L	S30403	304S11	58E	1.4301	X5CrNi18-10	2332	SUS 304L

ASME B16.49 Stub End Fittings Price List in Mumbai, Stainless Steel UNS S30403 Lap Joint Stub End Supplier in Mumbai, Stainless Steel DIN 1.4301 Pipes Fittings Exporter in West Mumbai, DIN 1.4301 Stainless Steel Tee Reducer Exporter in India, Stainless Steel 304L Stub End Exporter in Mumbai, Stainless Steel 304L Equal Cross in Mumbai, Stainless Steel 304L Long Radius Elbow Size Chart, 304L Stainless Steel Outlet Tee Fittings Price in Mumbai, ANSI B16.9 Tee Weight Chart, Stainless Steel 304L Outlet Elbow Supplier in India, WNR 1.4301 Stainless Steel 304L Pipe Fittings Stockist in Mumbai, Stainless Steel 304L 45° Elbows Supplier in India

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Types of Stainless Steel 304L Pipe Fittings

Are Custom Sizes Available for Stainless Steel 304L Pipe Fittings?

Yes, custom sizes are available for Stainless Steel 304L Pipe Fittings to meet specific requirements. We offer tailored solutions to ensure precise fit and performance for various applications. For more information, please contact us at sales@yashfittings.com

Stainless Steel 304L Short Radius Elbow Sizes in mm, ASME B16.49 90 Deg. Elbow Manufacturer in West Mumbai, Stainless Steel UNS S30403 Pipe Fittings Thickness, Stainless Steel 304L Pipe Fittings Supplier in Mumbai, Stainless Steel 304L Eccentric Reducer Exporter in Mumbai, Stainless Steel 304L Cross Fittings Price List in India, WNR 1.4301 Stainless Steel 304L Stub End Distributor in Mumbai, Stainless Steel UNS S30403 Pipe Fittings Supplier in West Mumbai, Stainless Steel 304L Outlet Elbow Distributor in India

Appllication Industry of Stainless Steel 304L Pipe Fittings

304L stainless steel pipe fittings are broadly applied in industrial applications where maximum corrosion resistance and durability are essential. Typical areas of application cover food processing, chemical processing, pharmaceuticals, and petrochemicals where the fittings retain cleanliness and act against corrosive materials. Additionally, they apply in water treatment facilities, heat exchangers, and equipment used in dairies because they possess superior protection against oxidation as well as rust. Their low carbon levels render them well suited for welding use, which guarantees long-term performance at high temperature and high pressure, enhancing their applicability in a wide range of industrial processes.
