Stainless Steel 347 / 347H Buttweld Fittings

Yash Fittings, with its headquarters in Mumbai, India, is a renowned producer and exporter of high-grade Stainless Steel 316TI Buttweld Fittings, providing quality piping solutions to various industries across the world. With its precision engineering and high standards of quality, Yash Fittings supplies a diverse assortment of buttweld fittings including elbows, tees, reducers, and caps. Made of Stainless Steel 316TI, a titanium-stabilized austenitic alloy, these fittings are particularly prized for their superior resistance to corrosion, high temperature, and intergranular attack, making them well-suited for demanding industrial use.

Stainless Steel 347 Pipe Elbow In India, Stainless Steel 347H Pipe Fittings United kingdom, SS 347 Buttweld Elbow Mumbai, Stainless Steel S34700 Seamless Fittings Exporter West Mumbai, Stainless Steel 1.4550 Butt Weld Pipe Fittings in Mumbai, Stainless Steel 347H Two Joint Pipe Fittings Mumbai, 347 Stainless Steel Welded Fittings Manufacturers in Mumbai, Stainless Steel 347H Buttweld Fittings In India, ASTM A403 WP3 347 Stainless Steel Buttweld Fittings Supplier in Mumbai, India.

Stainless Steel 347 / 347H Buttweld Fittings Specification

Specifications	ASME SA403 / ASTM A403
Dimension Standard	ASME/ANSI B16.9, MSS-SP-43/SP-79, ASME B16.28, ASME B16.25, ASME B16.49
Standard Size Range	1/2” NB TO 48” NB. (Fabricated, Seamless and 100% X-Ray Welded)
Manufacturing Type	Fabricated / Seamless / Welded / ERW
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D, or Custom
Wall Thickness / Schedule	SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS / 3mm – 40mm
End Connection	Butt Weld
Melting Point	1400-1450°C for (WP317)
Outside Diameter (OD)	Seamless / Buttweld Fitting ( 1/2″～48″), ERW / Welded / Fabricated Buttweld Fitting (1/2″～48″)
Value Added Services	Hot Dipped Galvanizing, Electro Polish, Sand Blasting, Epoxy & FBE Coating, Threading, Soldering
Other Standards	MSS SP-75, ISO, SNSI, JIS, DIN, GB, DIN2617, JISB2311, JISB2312, JISB2313 / T12459GB / T13401, SH3408, SH3409HG / T21635HG / T21631SY / T05010
Material Test Certificates (MTC)	As per EN 10204 3.2 and EN 10204 3.1, Certifying NACE MR0175, NACE MR0103
Materials	AISI 317
Two Halve / Two Joint Buttweld Fittings Size	6″ to 48″
Manufacturing Specification	ASME: ANSI B16.9, ANSI B16.28, ASME B16.25, MSS-SP-43, DIN: DIN2605, DIN2615, DIN2616, DIN2617, DIN28011, EN: EN10253-1, EN10253-2
A403 SS Seamless Fittings	Size: 15 NB to 300 NB \| Sch.& Swg: Sch.5 to Sch.XXs
A403 SS Welded Fittings	Size: 15 NB to 600 NB \| Sch.& Swg: Sch.5 to Sch.80s

Stainless Steel 316TI Buttweld Fittings have superior chemical, mechanical, and physical properties. Chemically, the presence of titanium enhances resistance to carbide precipitation, which further increases corrosion resistance in high-temperature conditions. Mechanically, they provide high tensile and yield strength, excellent creep resistance, and toughness at even elevated temperatures. Physically, the fittings show high thermal stability, good formability, weldability, and a smooth internal surface for unobstructed fluid flow. These characteristics make them ideal for harsh operating conditions of heat, pressure, and corrosive media.

Stainless Steel 347 / 347H Buttweld Fittings Chemical Composition

Element	C	Cr	Mn	Ni	P	S	Si	Cb/Ta
SS 347	0.08 max	min: 17.0 max: 20.0	2.0 max	min: 9.0 max: 13.0	0.04 max	0.30 max	0.75 max	min:10x C max: 1.0
SS 347H	min: 0.04 max: 0.10	min: 17.0 max: 20.0	2.0 max	min: 9.0 max: 13.0	0.03 max	0.30 max	0.75 max	min:10x C max: 1.0

Stainless Steel 347 / 347H Buttweld Fittings Mechanical Properties

Grade	Tensile Strength ksi (MPa) min	Yield Strength 0.2% ksi offset ksi (MPa) min	Elongation (% in 50mm) min	Hardness (Brinell) MAX	Hardness (Rockwell B) MAX
347/347H	75 (515)	30 (205)	40	201	95

ASTM A403 Stainless Steel 347 Buttweld Fittings Cross in India, Stainless Steel 1.4550 Buttweld Pipe Fittings United kingdom, SS 347H Butt Weld Pipe Cap Mumbai, Stainless Steel 347 Eccentric Reducer West Mumbai, Stainless Steel 347 Equal Tee Mumbai, 347H Stainless Steel Reducer in Mumbai, Stainless Steel 347 SR Elbow Exporter in Mumbai,

Largest Stainless Steel 347 / 347H Buttweld Fittings Supplier in Mumbai, India

Yash Fittings is a leading supplier of Stainless Steel 347 Buttweld Fittings in Mumbai, India. We offer an extensive range of Stainless Steel 347H Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Stainless Steel 347 / 347H Buttweld Fittings Equivalent Grade

STANDARD	UNS	WNR.	EN	JIS	GOST
SS 347	S34700	1.4550	X6CrNiNb18-10	SUS 347	08Ch18N12B
SS 347H	S34709	1.4961	X6CrNiNb18-12	SUS 347H	–

Why Choose Stainless Steel 347 / 347H Buttweld Fittings from Yash Fittings?

Stainless Steel 347 Buttweld Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

UNS S34709 Stub End Uk, ANSI B16.9 Stainless Steel 347 Pipe Fittings United kingdom, Stainless Steel 347H Pipe Bend Stockist in Mumbai, Stainless Steel 347 Pipe Nipple Manufacturer & Exporter in West Mumbai, Stainless Steel 1.4961 Butt Weld Pipe Fittings in Mumbai, Stainless Steel 347 Pipe Two Joint Pipe Fittings Mumbai, 347H Stainless Steel Pipe Welded Fittings Manufacturers in Mumbai, Stainless Steel 347 Pipe Butt weld Fittings In India, ASTM A403 Stainless Steel 347H Pipe Butt Weld Fittings Supplier in Mumbai, India.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Stainless steel 347 and 347H Buttweld Fittings provide excellent resistance to intergranular corrosion, making them ideal for high temperature applications These alloys contain columbium and tantalum to stabilize the material and prevent carbide precipitation during welding. They are highly resistant to oxidation, providing long-term durability under extreme conditions. Stainless steel 347 provides excellent woldability and is suitable for applications in industries such as aerospace, chemical processing, and electrical equipment. The high-carbon 347H variant provides good strength at high temperatures, making it ideal for high-pressure environments.

Types of Stainless Steel 347 / 347H Buttweld Fittings

Stainless Steel 347 / 347H Buttweld Fittings Dimensions Chart

Nominal Pipe Size (inches)	Outside Diameter		45°Elbows		90° Elbows		180° Returns
	Outside Diameter		Long Radius		Long Radius	Short Radius	Long Radius
	(mm)	(inches)	Center to Face (inches)	Radius (inches)	Center to Face (inches)	Center to Face (inches)	Center to Center (inches)	Back to face (inches)
1	33.4	1.315	7/8		1 1/2	1	3	2 3/16
1/2	21.3	0.840	5/8		1 1/2	–	2	1 7/8
3/4	26.7	1.050	7/16		1 1/8	–	2 1/4	1 11/16
1 1/4	42.2	1.660	1		1 7/8	1 1/4	3 3/4	2 3/4
1 1/2	48.3	1.900	1 1/8	3	2 1/4	1 1/2	4 1/2	3 1/4
2	60.3	2.375	1 3/8	4	3	2	6	4 3/16
2 1/2	73.0	2.875	1 3/4	5	3 3/4	2 1/2	7 1/2	5 3/16
3	88.9	3.500	2	6	4 1/2	3	9	6 1/4
3 1/2	101.6	4.000	2 1/4	7	5 1/4	3 1/2	10 1/2	7 1/4
4	114.3	4.500	2 1/2	8	6	4	12	8 1/4
5	141.3	5.563	3 1/8	10	7 1/2	5	15	10 5/16
6	168.3	6.625	3 3/4	12	9	6	18	12 5/16
8	219.1	8.625	5	12	12	8	24	16 5/16
10	273.1	10.750	6 1/4	15	15	10	30	20 3/8
12	323.9	12.750	7 1/2	18	18	12	36	24 3/8

Are Custom Sizes Available for Stainless Steel 347 / 347H Buttweld Fittings?

Yes, custom sizes for Stainless Steel 347 / 347H Buttweld Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com

ASTM A403 Stainless Steel 347 Butt Weld Cross in India, Stainless Steel 1.4449 Buttweld Pipe Fittings United kingdom, SS 347H Butt Weld Pipe Cap Mumbai, Stainless Steel 347 Eccentric Reducer West Mumbai, Stainless Steel 347H Equal Tee Mumbai, 347 Stainless Steel Reducer in Mumbai, SS 347H SR Elbow Exporter in Mumbai,

Application Industry of Stainless Steel 347 / 347H Buttweld Fittings

Stainless Steel 316TI Buttweld Fittings find extensive use in high–heat and corrosion-resistant industries. They are used in chemical processing, power generation, oil and gas, food and beverage, marine, and pharmaceutical applications. They are suitable for heat exchangers, pressure vessels, and piping systems that carry corrosive chemicals due to high temperature resistance and corrosion resistance. In food and pharmaceutical uses, they provide hygiene and durability. Their strength, thermal stability, and intergranular corrosion resistance render them appropriate for severe structures in industrial as well as high-temperature service applications.
