Stainless Steel 321 / 321H Buttweld Fittings

Yash Fittings, an Indian company in Mumbai, is a reliable producer and distributor of high-grade industrial pipe fittings known for precision engineering and durability. Of its extensive product portfolio, the company specializes in Stainless Steel 321/321H Buttweld Fittings, which are suitable for high-temperature applications because of their excellent resistance to intergranular corrosion and high mechanical strength. Grade 321 is titanium-stabilized, and 321H provides increased carbon content for improved creep resistance, which are applicable for the heat exchangers, chemical processing, and power generation sectors.

Stainless Steel 321 Pipe Elbow In India, Stainless Steel 321H Pipe Fittings United kingdom, SS 321 Buttweld Elbow Mumbai, Stainless Steel S32100 Seamless Fittings Exporter West Mumbai, Stainless Steel 1.4541 Butt Weld Pipe Fittings in Mumbai, Stainless Steel 321H Two Joint Pipe Fittings Mumbai, 321 Stainless Steel Welded Fittings Manufacturers in Mumbai, Stainless Steel 321H Buttweld Fittings In India, ASTM A403 WP3 321 Stainless Steel Buttweld Fittings Supplier in Mumbai, India.

Stainless Steel 321 / 321H Buttweld Fittings Specification

Specifications	ASME SA403 / ASTM A403
Dimension Standard	ASME/ANSI B16.9, MSS-SP-43/SP-79, ASME B16.28, ASME B16.25, ASME B16.49
Standard Size Range	1/2” NB TO 48” NB. (Fabricated, Seamless and 100% X-Ray Welded)
Manufacturing Type	Fabricated / Seamless / Welded / ERW
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D, or Custom
Wall Thickness / Schedule	SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS / 3mm – 40mm
End Connection	Butt Weld
Melting Point	1400-1450°C for (WP321)
Outside Diameter (OD)	Seamless / Buttweld Fitting ( 1/2″～48″), ERW / Welded / Fabricated Buttweld Fitting (1/2″～48″)
Value Added Services	Hot Dipped Galvanizing, Electro Polish, Sand Blasting, Epoxy & FBE Coating, Threading, Soldering
Other Standards	MSS SP-75, ISO, SNSI, JIS, DIN, GB, DIN2617, JISB2311, JISB2312, JISB2313 / T12459GB / T13401, SH3408, SH3409HG / T21635HG / T21631SY / T05010
Material Test Certificates (MTC)	As per EN 10204 3.2 and EN 10204 3.1, Certifying NACE MR0175, NACE MR0103
Materials	AISI 321
Two Halve / Two Joint Buttweld Fittings Size	6″ to 48″
Manufacturing Specification	ASME: ANSI B16.9, ANSI B16.28, ASME B16.25, MSS-SP-43, DIN: DIN2605, DIN2615, DIN2616, DIN2617, DIN28011, EN: EN10253-1, EN10253-2
A403 SS Seamless Fittings	Size: 15 NB to 300 NB \| Sch.& Swg: Sch.5 to Sch.XXs
A403 SS Welded Fittings	Size: 15 NB to 600 NB \| Sch.& Swg: Sch.5 to Sch.80s

Stainless Steel 321/321H Buttweld Fittings have superior chemical, mechanical, and physical properties, making them suitable for high-temperature and corrosive conditions. Chemically, they are stabilized austenitic stainless steels with the addition of titanium to resist intergranular corrosion particularly following welding. Grade 321H has a higher carbon content than 321, improving its high-temperature strength. Mechanically, the fittings have excellent tensile strength, creep resistance, and stress rupture properties, with normal tensile strength of about 515 MPa and yield strength of 205 MPa. Physically, they possess structural stability at high temperature and contain good oxidation resistance up to 900°C.

Stainless Steel 321 / 321H Buttweld Fittings Chemical Composition

Grade	C	Mn	Si	P	S	Cr	N	Ni	Ti
SS 321	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	17.00 – 19.00	0.10 max	9.00 – 12.00	5(C+N) – 0.70 max
SS 321H	0.04 – 0.10	2.0 max	1.0 max	0.045 max	0.030 max	17.00 – 19.00	0.10 max	9.00 – 12.00	4(C+N) – 0.70 max

Stainless Steel 321 / 321H Buttweld Fittings Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.0 g/cm3	1457 °C (2650 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

ASTM A403 Stainless Steel 321 Buttweld Fittings Cross in India, Stainless Steel 1.4449 Buttweld Pipe Fittings United kingdom, SS 321H Butt Weld Pipe Cap Mumbai, Stainless Steel 321 Eccentric Reducer West Mumbai, Stainless Steel 321H Equal Tee Mumbai, 321 Stainless Steel Reducer in Mumbai, Stainless Steel 321H SR Elbow Exporter in Mumbai,

Largest Stainless Steel 321 / 321H Buttweld Fittings Supplier in Mumbai, India

Yash Fittings is a leading supplier of Stainless Steel 321 Buttweld Fittings in Mumbai, India. We offer an extensive range of Stainless Steel 321H Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Stainless Steel 321 / 321H Buttweld Fittings Equivalent Grade

STANDARD	WERKSTOFF NR.	UNS	JIS	EN
SS 321	1.4541	S32100	SUS 321	X6CrNiTi18-10
SS 321H	1.4878	S32109	SUS 321H	X12CrNiTi18-9

Why Choose Stainless Steel 321 / 321H Buttweld Fittings from Yash Fittings?

Stainless Steel 321 Buttweld Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

UNS S32109 Stub End Uk, ANSI B16.9 Stainless Steel 321 Pipe Fittings United kingdom, Stainless Steel 321H Pipe Bend Stockist in Mumbai, Stainless Steel 321 Pipe Nipple Manufacturer & Exporter in West Mumbai, Stainless Steel 1.4878 Butt Weld Pipe Fittings in Mumbai, Stainless Steel 321H Pipe Two Joint Pipe Fittings Mumbai, 321 Stainless Steel Pipe Welded Fittings Manufacturers in Mumbai, Stainless Steel 321 Pipe Butt weld Fittings In India, ASTM A403 Stainless Steel 321H Pipe Butt Weld Fittings Supplier in Mumbai, India.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Types of Stainless Steel 321 / 321H Buttweld Fittings

Stainless Steel 321 / 321H Buttweld Fittings Dimensions Chart

Nominal Pipe Size (inches)	Outside Diameter		45°Elbows		90° Elbows		180° Returns
	Outside Diameter		Long Radius		Long Radius	Short Radius	Long Radius
	(mm)	(inches)	Center to Face (inches)	Radius (inches)	Center to Face (inches)	Center to Face (inches)	Center to Center (inches)	Back to face (inches)
1	33.4	1.315	7/8		1 1/2	1	3	2 3/16
1/2	21.3	0.840	5/8		1 1/2	–	2	1 7/8
3/4	26.7	1.050	7/16		1 1/8	–	2 1/4	1 11/16
1 1/4	42.2	1.660	1		1 7/8	1 1/4	3 3/4	2 3/4
1 1/2	48.3	1.900	1 1/8	3	2 1/4	1 1/2	4 1/2	3 1/4
2	60.3	2.375	1 3/8	4	3	2	6	4 3/16
2 1/2	73.0	2.875	1 3/4	5	3 3/4	2 1/2	7 1/2	5 3/16
3	88.9	3.500	2	6	4 1/2	3	9	6 1/4
3 1/2	101.6	4.000	2 1/4	7	5 1/4	3 1/2	10 1/2	7 1/4
4	114.3	4.500	2 1/2	8	6	4	12	8 1/4
5	141.3	5.563	3 1/8	10	7 1/2	5	15	10 5/16
6	168.3	6.625	3 3/4	12	9	6	18	12 5/16
8	219.1	8.625	5	12	12	8	24	16 5/16
10	273.1	10.750	6 1/4	15	15	10	30	20 3/8
12	323.9	12.750	7 1/2	18	18	12	36	24 3/8

Are Custom Sizes Available for Stainless Steel 321 / 321H Buttweld Fittings?

Yes, custom sizes for Stainless Steel 321 / 321H Buttweld Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com

ASTM A403 Stainless Steel 321 Butt Weld Cross in India, Stainless Steel 1.4878 Buttweld Pipe Fittings United kingdom, SS 321H Butt Weld Pipe Cap Mumbai, Stainless Steel 321 Eccentric Reducer West Mumbai, Stainless Steel 321H Equal Tee Mumbai, 321 Stainless Steel Reducer in Mumbai, SS 321H SR Elbow Exporter in Mumbai,

Application Industry of Stainless Steel 321 / 321H Buttweld Fittings

Stainless Steel 321/321H Buttweld Fittings have vast applications in high-temperature and corrosive conditions because of their superior strength and oxidation resistance. They are typically used in heat exchangers, exhaust systems, furnace components, and aircraft components. They are also utilized in chemical processing, petrochemical facilities, power generation, and refinery processes. The higher carbon content in 321H allows it to be used in pressure vessels and boiler equipment. Their stability and resistance to thermal stress enable them to be suitable for use in systems that demand consistent performance to 900°C.
