Yash Fittings, based in Mumbai, India, is a well-known exporter and producer of high-quality industrial pipe fittings, providing dependable solutions to industries globally. Some of their top products include Inconel Buttweld Fittings, which are produced using high-performance nickel-based alloys that provide brilliant resistance to heat, oxidation, and corrosion. The fittings, comprising different grades of Inconel, are suitable for corrosive and high-temperature applications. Inconel Buttweld Fittings find extensive application in chemical processing, aerospace, and power generation sectors with the assurance of strength and dependability in harsh operational environments.
| Specifications | ASTM B 366 / ASME SB 366 |
| Standards | ANSI B 16.5, BS 1560. BS 10, IS 6392, B-2.1 NPT, API, DIN, JIS. MSS SP 44 |
| Size Range | Seamless 1/2″ – 10″ , Welded 1/2″ – 48″ |
| Type | Seamless & 100% X-Ray Welded, Fabricated |
| Schedule | Sch 5 TO Sch XXS. |
| Pipe Fittings Type | Reducer (Concentric & Eccentric), CAP, Stubend (Long &Short), Nipple (Barrel), Bend (Long & Short), Elbow (180 Deg., 90 Deg. & 45 Deg.), Tee (Equal & Unequal) |
Inconel Buttweld Fittings are constructed with high-performance nickel-chromium alloys, which show superior chemical, mechanical, and physical properties. Chemically, Inconel alloys exhibit top-notch resistance towards oxidation, corrosion, and carburization under even harsh surroundings like high temperature and aggressive chemicals. Mechanically, Inconel Buttweld Fittings have high tensile strength, good fatigue strength and creep property, and impressive structural integrity even at high temperature. They are physically very good in weldability, toughness, and thermal stability and even retain their properties under cryogenic temperatures, thus being particularly suitable for application in aerospace, chemical processing, and power generation industries.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
Yash Fittings is a leading supplier of Inconel Buttweld Fittings in Mumbai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
| Inconel 718 | 2.4668 | N07718 | – | – | – | – | – |
Inconel Buttweld Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Inconel Buttweld Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Inconel Buttweld Fittings find broad application in processes that demand greater strength, high-temperature oxidation, and corrosion resistance. Such fittings are perfect for chemical processing, aerospace engineering, nuclear plants, and shipbuilding, where exposure to hostile conditions is regular. They find application in heat exchangers, gas turbines, pollution abatement systems, and furnace equipment. Inconel Buttweld Fittings provide reliability and performance in harsh environments, with long service life, low maintenance, and superior resistance to thermal fatigue, oxidation, and pressure conditions.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
