Yash Fittings, a leading Mumbai, India-based manufacturer and supplier of industrial pipe fittings, is renowned for providing precision and reliability in varied industries. Some of its innovative products include Inconel 718 Pipe Fittings, manufactured from a highly corrosion-resistant and high-strength nickel-chromium alloy. Inconel 718 has very good tensile strength, resistance to fatigue, and high creep-rupture strength, thereby being suitable for harsh environments. This grade is particularly suitable for use in aerospace, marine, and chemical processing applications because it can handle high temperatures, pressure, and aggressive corrosive media.
| Specification : | ASTM B366, ASTM SB 366, ASTM B564, ASME SB564 |
| Dimensions : | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
| Size : | ½”NB to 24″NB in Sch 10s, 40s, 80s, 160s, XXS. |
| Thickness : | Sch Sch 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160 Sch XXS |
| Types : | Seamless / ERW / Welded / Fabricated |
| Grades : | Inconel 718 – UNS N06600, Inconel 718 – UNS N06601 Inconel 718 – UNS N06625 Incoloy 800 – UNS N08800, Incoloy 800H / HT – UNS N08810, Incoloy 825 – UNS N08825 |
Inconel 718 Pipe Fittings have excellent chemical, mechanical, and physical properties, which make them suitable for high-temperature, high-stress applications. Chemically, Inconel 718 is a nickel-chromium alloy with molybdenum, niobium, and titanium, which improve its resistance to oxidation, corrosion, and carburization in harsh environments. Mechanically, it has excellent tensile strength of up to 1,300 MPa, with excellent fatigue and creep resistance at temperatures of up to 700°C. Physically, Inconel 718 has good structural integrity at very high temperatures, welds well, and provides excellent resistance to thermal fatigue, thus being ideal for aerospace, power generation, and chemical industries.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti | Nb |
| 718 | 0.08 | 0.35 | 0.35 | 0.01 | 0.3 | bal | 50.0 – 55.0 | 17.00 – 21.00 | 0.2 – 0.8 | 0.7 – 1.15 | 4.75 – 5.5 |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 70,000 , MPa – 482 | Psi – 1,35,000 , MPa -930 | 45 % |
Yash Fittings is a leading supplier of Inconel 718 Pipe Fittings in Mumbai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR |
| Inconel 718 | N07718 | 2.4668 | NC19FeNb |
Inconel 718 Pipe Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| Nominal Thickness (in) MM | Pipe Size (in) | Transverse Areas (in2) MM2 | Diameter (in) MM | Volume (ft3/ft) | Number of Threads per inch of Screw | Weight | Length of Pipe (ft per sq.0 foot of surface) | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Internal | External | Steel | Internal | External | (kg/m) | (lb/ft) | Internal Surface (ft) | External Surface (ft) | ||||
| 0.007 | 1/8 | 0.006 | 0.013 | 0.007 | 0.027 | 0.0405 | 0.00004 | 27 | 0.036 | 0.024 | 14.020 | 9.043 |
| 0.009 | ¼ | 0.010 | 0.023 | 0.013 | 0.036 | 0.0540 | 0.00007 | 18 | 0.063 | 0.042 | 10.049 | 7.007 |
| 0.009 | 3/8 | 0.019 | 0.036 | 0.017 | 0.049 | 0.0675 | 0.00013 | 18 | 0.084 | 0.057 | 7.075 | 5.066 |
| 0.011 | ½ | 0.030 | 0.055 | 0.025 | 0.062 | 0.0840 | 0.00021 | 14 | 1.026 | 0.085 | 6.014 | 4.055 |
| 0.011 | ¾ | 0.053 | 0.087 | 0.033 | 0.082 | 1.0050 | 0.00037 | 14 | 1.068 | 1.013 | 4.064 | 3.064 |
| 0.013 | 1 | 0.086 | 1.036 | 0.049 | 1.005 | 1.0315 | 0.00060 | 11 ½ | 2.050 | 1.068 | 3.064 | 2.090 |
| 0.014 | 1 ¼ | 1.050 | 2.016 | 0.067 | 1.038 | 1.0660 | 0.00104 | 11 ½ | 3.038 | 2.027 | 2.077 | 2.030 |
| 0.015 | 1 ½ | 2.004 | 2.084 | 0.080 | 1.061 | 1.0900 | 0.00141 | 11 ½ | 4.004 | 2.072 | 2.037 | 2.001 |
| 0.015 | 2 | 3.036 | 4.043 | 1.008 | 2.007 | 2.0375 | 0.00233 | 11 ½ | 5.043 | 3.065 | 1.085 | 1.061 |
| 0.020 | 2 ½ | 4.079 | 6.049 | 1.070 | 2.047 | 2.0875 | 0.00333 | 8 | 8.062 | 5.079 | 1.055 | 1.033 |
| 0.022 | 3 | 7.039 | 9.062 | 2.023 | 3.007 | 3.0500 | 0.00513 | 8 | 11.027 | 7.058 | 1.025 | 1.009 |
| 0.023 | 3 ½ | 9.089 | 12.056 | 2.068 | 3.055 | 4.0000 | 0.00687 | 8 | 13.056 | 9.011 | 1.008 | 0.095 |
| 0.024 | 4 | 12.073 | 15.090 | 3.017 | 4.003 | 4.0500 | 0.00884 | 8 | 16.006 | 10.079 | 0.095 | 0.085 |
| 0.026 | 5 | 20.000 | 24.030 | 4.030 | 5.005 | 5.0563 | 0.01389 | 8 | 21.074 | 14.061 | 0.076 | 0.069 |
| 0.028 | 6 | 28.089 | 34.047 | 5.058 | 6.007 | 6.0625 | 0.02006 | 8 | 28.023 | 18.097 | 0.063 | 0.058 |
| 0.032 | 8 | 50.002 | 58.042 | 8.040 | 7.098 | 8.0625 | 0.03552 | 8 | 42.049 | 28.055 | 0.048 | 0.044 |
|
3 1/2″ IPS( 4.000″O. D.) |
1/8″ IPS(.405″O. D.) |
|---|---|
|
SCH 40, 10, 160, 80, XXH |
SCH 40, 80 |
|
4″ IPS(4.500″O. D.) |
1/4″ IPS(.540″O. D.) |
|
SCH 40, 10, 160, 80, XXH |
SCH 40, 10, 80 |
|
5″ IPS( 5.563″O. D.) |
3/8″ IPS(.675″O. D.) |
|
SCH 40, 10, 160, 80, XXH |
SCH 40, 10, 80 |
|
6″ IPS(6.625″O. D.) |
1/2″ IPS(.840″O. D.) |
|
SCH 10, 5, 80, 40, 160, 120 XXH |
SCH 5, 40, 10, 160, 80, XXH |
|
8 ” IPS(8.625″O. D.) |
3/4″ IPS(1.050″O. D.) |
|
SCH 10, 5, 80, 40, 160, 120 XXH |
SCH 40, 10, 160, 80, XXH |
|
10″ IPS(10.750″O. D.) |
1″ IPS:(1.315′O. D.) |
|
SCH 10, 20, TRUE 80(.500), 40, 80 (.500), |
SCH 5, 40, 10, 160, 80, XXH |
|
12″ IPS(12.750″O. D.) |
1-1/4″ IPS(1.660″O. D.) |
|
SCH 10, 20, TRUE40(.406), 40(.375), SCH80(.500) |
SCH 40, 10, 160, 80, XXH |
|
14″ IPS(14.000″O. D.) |
1-1/2″ IPS(1.900″O. D.) |
|
SCH10(.188), SCH40(.375) |
SCH 40, 10, 160, 80, XXH |
|
16″ IPS(16.000″O. D.) |
2″ IPS(2.375″O. D.) |
|
SCH10(.188), SCH40(.375) |
SCH 40, 10, 160, 80, XXH |
|
18″ IPS (18.000″O. D.) |
2 1/2″ IPS(2.875″O. D.) |
Yes, custom sizes for Inconel 718 Pipe Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Inconel 718 Pipe Fittings are extensively used in applications where the material must withstand high temperatures, high pressure, and corrosive conditions. They find extensive use in aerospace engineering, such as in the turbine engines of aircraft, rocket motors, and tanks for cryogenic fluids, because of their high strength and resistance to thermal fatigue. It also finds usage in power generation, chemical processing, and marine environments. The performance of Inconel 718 under high stress conditions and oxidation resistance make it suitable for service in high-temperature gas environments, jet engine components, and other high-performance systems.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
