Yash Fittings, established in Mumbai, India, is one of the top manufacturers and suppliers of excellent industrial pipe fittings, renowned for its accuracy and dependability. Alloy Steel Forged Fittings is one of its high-end products made from tough, long-lasting materials engineered to resist high pressure and temperature situations. These fittings, which are manufactured from alloys like F11 and F22, exhibit superior mechanical properties like high tensile strength and heat and corrosion resistance. They find extensive application in power plants, petrochemical plants, and refineries for high-performance use.
| Specifications | Alloy Steel |
|---|---|
| Size | 1/8” NB TO 48” NB. |
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Type | Seamless / Welded / Fabricated |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
Alloy Steel Forged Fittings display outstanding chemical, mechanical, and physical properties and are well suited for high-temperature and high-pressure applications. Chemically, alloy steels F11 and F22 have chromium, molybdenum, and vanadium, which improve their strength, corrosion resistance, and oxidation resistance. Mechanically, the forged fittings possess high tensile strength (up to 700 MPa), good hardness, and superior creep and fatigue resistance, thus providing durability even at severe conditions. Physically, alloy steel fittings retain their strength in high temperatures, are considerably resistant to thermal stress, and provide fair weldability and formability that makes them appropriate for critical industrial use.
| Grade | C | Mn | Si | S | P | Cr | Mo |
| Alloy Steel | 0.08 – 0.12 | 0.3 – 0.6 | 0.5 | 0.01 | 0.02 | 8.5 – 9.5 | 0.85 – 1.05 |
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| Alloy Steel | 415 | 585 | 20 |
Yash Fittings is a leading supplier of Alloy Steel Forged Fittings in Mumbai, India. We offer an extensive range of Alloy Steel Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Alloy Steel Forged Fittings from Yash Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Yes, custom sizes for Alloy Steel Forged Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
| NPS | Outside diameter D | 45° Long Rad Center to End B | 90° Long Rad Center to End A | 45° 3D Center to End B | 90° 3D Center to End A |
| 1/2 | 21.03 | 16 | 38 | ||
| 3/4 | 26.07 | 19 | 38 | 24 | 57 |
| 1 | 33.04 | 22 | 38 | 31 | 76 |
| 1¼ | 42.02 | 25 | 48 | 39 | 95 |
| 1½ | 48.03 | 29 | 57 | 47 | 114 |
| 2 | 60.03 | 35 | 76 | 63 | 152 |
| 2½ | 73 | 44 | 95 | 79 | 190 |
| 3 | 88.09 | 51 | 114 | 95 | 229 |
| 3½ | 101.06 | 57 | 133 | 111 | 267 |
| 4 | 114.03 | 64 | 152 | 127 | 305 |
| 5 | 141.03 | 79 | 190 | 157 | 381 |
| 6 | 168.03 | 95 | 229 | 189 | 457 |
| 8 | 219.01 | 127 | 305 | 252 | 610 |
| 10 | 273 | 159 | 381 | 316 | 762 |
| 12 | 323.08 | 190 | 457 | 378 | 914 |
| 14 | 355.06 | 222 | 533 | 441 | 1067 |
| 16 | 406.04 | 254 | 610 | 505 | 1219 |
| DN (Normal Pipe Size) For ASME B16.9 | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Alloy Steel Forged Fittings are extensively applied in high-strength, heat-resistant, and long-lasting fittings required in industries. They are best suited for use in power plants, refineries, petrochemical industries, and oil and gas industries, where high pressure and temperature are prevalent. They are frequently utilized in steam lines, boilers, pressure vessels, and heat exchangers. The superior mechanical qualities of alloy steel forged fittings, such as creep, oxidation, and corrosion resistance, render them ideal for critical applications demanding long-term performance and reliability under harsh conditions.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
