Yash Fittings, established in Mumbai, India, is a leading pipe fittings manufacturer and supplier with high-quality products to offer a variety of solutions to industries all over the globe. From its top-of-the-line products, the Alloy Steel F1 Forged Fittings are particularly notable for their extraordinary strength and resilience. The fittings are produced using Alloy Steel F1, which is also renowned for being resistant to high pressure and heat. Offered in numerous grades such as ASTM A105, these forged fittings provide consistent performance and long life service in severe industrial processes.
| Standards | ASTM A182 / ASME SA182 |
| Specifications | ASME B16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size Range | NPS 1/8″- 4″ (DN 6~100) |
| Rating Pressure | Threaded End – 2000/3000/6000 LBS. Socket weld End – 3000/6000/9000 LBS. |
| Type | Socket Weld, Screwed, BSP Threaded & NPT Threaded |
Alloy Steel F1 Forged Fittings are constructed of an alloy mixture that contains carbon, manganese, and chromium, which gives them superior corrosion resistance and thermal stability. Chemically, they are formulated to withstand aggressive environments and avoid oxidation. Mechanically, these fittings have high tensile strength, making them capable of handling high-pressure systems without loss of structural integrity. Physically, Alloy Steel F1 Forged Fittings possess great hardness, impact strength, and toughness, which make them extremely dependable for long-term applications in high-temperature as well as high-pressure conditions.
| Grade | C | Mn | Si | S | P | Cr | Mo |
| F1 | 0.15 max | 0.3-0.6 | 0.5 | 0.03 | 0.03 | 4-6 | 0.44-0.65 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min |
| F1 | 275 | 485 | 20 |
Yash Fittings is a leading supplier of Alloy Steel F1 Forged Fittings in Mumbai, India. We offer an extensive range of Alloy Steel F1 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Alloy Steel F1 Forged Fittings from Yash Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Yes, custom sizes for Alloy Steel F1 Forged Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
| DN-NPT | MAJOR DIAMETER MM | TAPPING /DRILL SIZE MM | TPI | PITCH MM |
|---|---|---|---|---|
| 1/16″ | 7.895 | 6.00 | 27 | 0.941 |
| 1/8″ | 10.242 | 8.25 | 27 | 0.941 |
| 1/4″ | 13.616 | 10.70 | 18 | 1.411 |
| 3/8″ | 17.055 | 14.10 | 18 | 1.411 |
| 1/2″ | 21.223 | 17.40 | 14 | 1.814 |
| 3/4″ | 26.568 | 22.60 | 14 | 1.814 |
| 1″ | 33.228 | 28.50 | 11.5 | 2.209 |
| 1¼” | 41.985 | 37.00 | 11.5 | 2.209 |
| 1½” | 48.054 | 43.50 | 11.5 | 2.209 |
| 2″ | 60.092 | 55.00 | 11.5 | 2.209 |
| 2½” | 72.699 | 65.50 | 8 | 3.175 |
| 3″ | 88.608 | 81.50 | 8 | 3.175 |
| 3½” | 101.316 | 94.30 | 8 | 3.175 |
| 4″ | 113.973 | 107.00 | 8 | 3.175 |
| 5″ | 141.300 | 134.384 | 8 | 3.175 |
| 6″ | 168.275 | 161.191 | 8 | 3.175 |
| 8″ | 219.075 | 211.673 | 8 | 3.175 |
| 10″ | 273.050 | 265.311 | 8 | 3.175 |
| 12″ | 323.850 | 315.793 | 8 | 3.175 |
| Description | Class Designation | ||
|---|---|---|---|
| 3000 | 6000 | 9000 | |
| Elbows 45 and 90 degrees, Tees, Crosses, Couplings, Half-Couplings, End or Pipe Caps | 1/2 – 4 | 1/2 – 2 | 1/2 – 2 |
| 1/2 – 4 | 1/2 – 2 | 1/2 – 2 | |
| 1/2 – 4 | 1/2 – 2 | 1/2 – 2 | |
| Pipe Size by Wall Thickness | SCH 80 / XS | SCH 160 | XXS |
Alloy Steel F1 Forged Fittings are used extensively in power generation, petrochemical, chemical processing, and the oil and gas industry. They are required to provide leak-proof connections and efficient fluid flow in high-pressure pipelines. Alloy Steel F1 Forged Fittings are frequently used in applications where reliability and strength are extremely important, including the case of steam, gas, and fluid transmission systems. Their strong characteristics qualify them for applications that need high thermal stability and mechanical stress resistance.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
