Yash Fittings, based in Mumbai, India, is a well-known manufacturer and supplier of high-quality pipe fittings, recognized for providing consistent solutions to various industries. Some of its specialty products include Nickel Alloy 201 Forged Fittings, which are produced from a commercially pure wrought nickel grade with low carbon content. These fittings have superior corrosion resistance, particularly in caustic and reducing environments, as well as high thermal and electrical conductivity. Nickel 201 forged fittings are common in chemical processing, marine, food handling, and electronics industry due to their high strength, ductility, and stability under high stress conditions.
Specifications : ASTM B564 / ASTM SB 564
Type : Socketweld Fittings, Screwed-Threaded Fittings
Size : ⅛” to 4”
Class :2000 LBS, 3000 LBS, 6250 LBS, 9000 LBS
Standards : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Nickel Alloy 201 Forged Fittings offer superior chemical, mechanical, and physical properties that qualify them for highly corrosive and high-temperature service applications. Chemically, they consist of 99.6% pure nickel containing less than 0.02% carbon, thus reducing the possibility of graphitization and improving performance under high temperatures. Mechanically, they possess good tensile strength of about 403 MPa, high ductility, and good impact and stress corrosion cracking resistance. Physically, Nickel 201 possesses a high melting point of about 1446°C, a density of 8.89 g/cm³, and good thermal as well as electrical conductivity, making these fittings suitable for challenging industrial purposes.
| Nickel 201 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| Balance | 0.15 max | – | 0.35 max | 0.35 max | 0.40 max | – | 0.01 max | 0.25 max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
Yash Fittings is a leading supplier of Nickel Alloy 201 Forged Fittings in Mumbai, India. We offer an extensive range of Nickel Alloy 201 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Density (Kg.m-1) | 84.3 |
|---|---|
| Magnetic Permeability (20°C) | <1.005 |
| Curie Temperature (°C) | -90 |
| Young’s Modulus (N/mm2) | 179 x 103 |
| Specific Heat, 20°C (J.Kg-1.°K-1) | 418 |
| Specific Electrical Resistance, 20°C (?O.m) | 0.62 |
| Thermal conductivity,20°C (W.m-1.°K-1) | 17.5 |
| Mean coefficient of thermal expansion, 20-100°C (°K-1) | 13.4 x 10-6 |
| STANDARD | WERKSTOFF NR. | UNS | AFNOR | GOST | JIS | BS | EN | OR |
| Nickel 201 | 2.4068 | N02201 | – | НП-2 | NW 2201 | NA 12 | LC-Ni 99 | – |
Nickel Alloy 201 Forged Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Nickel Alloy 201 Forged Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Nickel Alloy 201 Forged Fittings have broad application in industries demanding outstanding resistance to corrosive and high-temperature environments. These fittings find optimal applications in chemical processing facilities, particularly in caustic alkalies, acids, and neutral salt handling systems. They also find application in marine services, food processing equipment, power generation equipment, and electronics manufacturing due to their superior thermal and electrical conductivity. Also, their ductility and strength qualify them for reactors, heat exchangers, and pressure vessels, providing long-term reliability and performance in high-stress and critical applications.
