Yash Fittings is a well-established manufacturer and supplier of superior pipe fittings, flanges, valves, and other industrial products. Having years of experience, the company offers a vast assortment of products that conform to international standards, providing reliability and performance in numerous industries. Amongst their niche products are Nickel Alloy 200 forged fittings that are characterized by superior corrosion resistance and strength. Nickel Alloy 200, a grade of pure nickel, finds extensive use in industries demanding corrosive environment resistance, including chemical processing and offshore applications.
| ASTM B564 – ASME SB564 | Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings |
| ASME B16.9 | Factory-Made Wrought Buttwelding Fittings |
| ASME B16.11 | Socket Welding and Threaded Forged Fittings |
| MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
Nickel Alloy 200 forged fittings have a special blend of chemical, mechanical, and physical properties that qualify them for service in extreme environments. Chemically, they consist of 99% pure nickel with excellent corrosion resistance, especially in alkaline and acid environments, and stress corrosion cracking resistance. Mechanically, Nickel Alloy 200 has superior strength and good ductility and can be used in high-pressure vessels and dynamic uses. It is also resistant to retaining its mechanical properties at high temperatures. Physically, the alloy has good thermal and electrical conductivity, has low magnetic permeability, and is highly formable. These physical properties guarantee that Nickel Alloy 200 forged fittings will function satisfactorily in extreme industries like chemical processing, aerospace, and marine uses.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
Yash Fittings is a leading supplier of Nickel Alloy 200 Forged Fittings in Mumbai, India. We offer an extensive range of Nickel Alloy 200 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Density (Kg.m-1) | 84.3 |
|---|---|
| Magnetic Permeability (20°C) | <1.005 |
| Curie Temperature (°C) | -90 |
| Young’s Modulus (N/mm2) | 179 x 103 |
| Specific Heat, 20°C (J.Kg-1.°K-1) | 418 |
| Specific Electrical Resistance, 20°C (?O.m) | 0.62 |
| Thermal conductivity,20°C (W.m-1.°K-1) | 17.5 |
| Mean coefficient of thermal expansion, 20-100°C (°K-1) | 13.4 x 10-6 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
Nickel Alloy 200 Forged Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Nickel Alloy 200 Forged Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Nickel Alloy 200 forged fittings are found in common use by industries demanding high seawater corrosion resistance and high temperatures. They are commonly found in chemical processing, where they are utilized in pipe, valves, and fittings that deal with corrosive materials such as alkalis and acids. They find applications in marine environments as well due to their superior resistance to seawater corrosion. Other sectors like aerospace, food processing, and electronics use Nickel Alloy 200 due to its hardness, electrical conductivity, and resistance to harsh environments, which guarantee enduring performance in systems where reliability is paramount.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
