Yash Fittings in Mumbai, India, is a prominent manufacturer and supplier of industrial pipe fittings of high quality, providing dependable solutions for various industries such as petrochemicals, power generation, and construction. Among its high-end products are Incoloy 825 Forged Fittings, produced from a nickel-iron-chromium alloy with superior resistance to corrosion, oxidation, and stress-corrosion cracking. The Incoloy 825 grade is best suited to be applied in extreme environments where corrosion resistance and high strength are required, and as a result, it is used considerably in chemical processing, pollution control, and marine environments.
| ASTM B564 Incoloy Alloy 825 Forged Fittings Specification | |
|---|---|
| Specifications | ASTM B564 / ASME SB564 |
| Standards | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8″ NB to 4″ NB (Socketweld & Screwed-Threaded) |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type | Socket Weld (S/W) & SCREWED (SCRD) – NPT, BSP, BSPT |
| Gr.825 Incoloy Alloy Forged Pipe Fittings Chemical Composition | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Grade | Ni | C | Fe | Si | Mn | S | Al | Ti | Cu | Cr | Mb |
| Incoloy 825 | 38.0 – 46.0 | 0.05 max | 22.0 min | 0.5 max | 1.0 max | 0.03 max | 0.2 max | 0.6 – 1.2 | 1.5 – 3.0 | 19.5 – 23.5 | 2.5 – 3.5 |
| Incoloy 825 Forged Fittings Mechanical Properties | |||||
|---|---|---|---|---|---|
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000, MPa -550 | Psi – 32,000, MPa – 220 | 30 % |
| Incoloy ASTM B564 Forged Fittings Equivalent Grades | ||||||||
|---|---|---|---|---|---|---|---|---|
| STANDARD | UNS | WNR NO. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 825 | N08825 | 2.4858 | NFE30C20DUM | NiCr21Mo | NCF 825 | NA 16 | ЭП703 | XH38BT |
Incoloy 825 Forged Fittings have outstanding chemical, mechanical, and physical properties making them well-suited for corrosive and high-temperature environments. Chemically, Incoloy 825 is a nickel-iron-chromium alloy containing additions of molybdenum, copper, and titanium that have a high resistance to corrosion, pitting, and stress-corrosion cracking. Mechanically, Incoloy 825 has high tensile strength, high ductility, and good thermal fatigue and fatigue resistance. Physically, these fittings retain their structural integrity at both high and low temperatures, providing superior resistance to oxidation and retaining good weldability, making them suitable for chemical processing, nuclear power, and marine use.
Yash Fittings is a leading supplier of Incoloy 825 Forged Fittings in Mumbai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy 825 Forged Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Incoloy 825 Forged Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Incoloy 825 Forged Fittings have extensive applications in industries where resistance to corrosion is high and there is a requirement for high-temperature performance. They are suited for chemical processing, nuclear reactors, marine settings, and pollution control systems where exposure to severe environments and corrosive materials is prevalent. They are also utilized in petrochemical refineries, heat exchangers, and flue gas desulfurization. The excellent stress-corrosion cracking, oxidation, and pitting resistance of Incoloy 825 makes it a consistent go-to for demanding applications requiring long-term performance and maximum strength under harsh environments.
