Yash Fittings is a reputable name in the industrial pipe fittings industry, famous for providing superior quality buttweld fittings that comply with international standards. Among its extensive portfolio of products, the company has expertise in Incoloy buttweld fittings, which are famous for having superior resistance against high temperatures and corrosive conditions. The fittings are widely employed in petrochemical industries, power plants, and marine engineering industries. Found in different grades such as Incoloy 800, 825, and 925, Yash Fittings provides durability, accuracy, and performance for the most stringent applications.
| Specifications | : | ASTM B366 / ASME SB366 |
| Size | : | Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″ |
| Standards | : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | : | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | : | Seamless / Welded / Fabricated |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
| 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
Incoloy buttweld fittings possess excellent physical, mechanical, and chemical properties to be suitable for demanding industrial purposes. Chemically, Incoloy fittings provide good resistance to oxidation, carburization, and corrosive environments of a broad spectrum because of high nickel, chromium, and iron content. In terms of mechanics, Incoloy fittings offer good tensile strength, fatigue resistance, and stability in harsh temperatures and pressures. Physically, they possess structural integrity at high temperatures and low thermal expansion ratios to guarantee efficient performance in high-temperature and high-stress environments that are frequent in chemical and power industries.
Yash Fittings is a leading supplier of Incoloy Buttweld Pipe Fittings in Mumbai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy Pipe Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Incoloy Pipe Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Incoloy buttweld fittings are commonly applied across industries that require resistance to heat, corrosion, and pressure to be high. They find use in chemical processing, power generation, marine, and oil & gas applications, where they join pipes firmly against severe conditions. The fittings are suited for heat exchangers, reactors, pressure vessels, and furnace equipment used at high temperatures. Their strength and resistance enable them to withstand both acidic and alkaline environments, providing long-term safety and reliability for critical applications and harsh operating conditions.
