Yash Fittings is a premium manufacturer and exporter of top-grade industrial fittings with expertise in producing a comprehensive variety of products for numerous industries such as oil and gas, chemical, power, and others. Their focus on precision and strength ensures that each fitting adheres to high standards required by the industry. Amongst their products, Yash Fittings offers Incoloy 800, 800H, and 800HT forged fittings, which are renowned for their high resistance to oxidation and corrosion in high-temperature applications. These alloys are best suited for application in severe environments and high-pressure operations, providing reliability and durability to challenging industries.
Incoloy Alloy 800/800H/800HT Forged Fittings Specification
Specifications ASTM B366 / ASME SB366
Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, MSS SP-79
Size 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Type Seamless / Welded / Fabricated
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Thickness Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Grade 800 / 800H / 800HT UNS (N08800, N08810, and N08811), DIN (1.4876, 1.4958, and 1.4959)
| Grade | Ni | Fe | Cr | Cu | Ti | Al | C | Mn | S | Si |
| Incoloy 800 | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .15-.60 | .15-.60 | .1 max | 1.5 max | .015 max | 1.0 max |
| Incoloy 800H | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .15-.60 | .15-.60 | .05-.10 max | 1.5 max | .015 max | 1.0 max |
| Incoloy 800HT | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .25-.60 | .85-1.20 | .06-.10 max | 1.5 max | .015 max | 1.0 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | Psi – 30,000 , MPa – 205 | 30 – 35 % |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32T |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4959 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
Incoloy 800, 800H, and 800HT forged fittings are well recognized for their superior chemical, mechanical, and physical properties to be highly appropriate for corrosive and high-temperature environments. Chemically, the alloys are mostly composed of nickel, iron, and chromium, whereas Incoloy 800H and 800HT have slightly more carbon content along with enhanced creep strength. Mechanically, they provide superior tensile strength, excellent weldability, and thermal fatigue and oxidation resistance. The alloys can resist very high temperatures up to 1100°F (593°C) and have good resistance to stress-corrosion cracking, guaranteeing strength under high-pressure as well as high-temperature conditions. Physically, Incoloy 800, 800H, and 800HT have good thermal conductivity and low expansion, along with improved strength retention at high temperatures, and are therefore best suited for applications in heat exchangers, boilers, and other high-stress industrial processes.
Yash Fittings is a leading supplier of Incoloy 800/ 800H/ 800HT Forged Fittings in Mumbai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yes, custom sizes for Incoloy 800/ 800H/ 800HT Forged Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Incoloy 800, 800H, and 800HT forged fittings are extensively employed in industries with the need for materials resistant to high temperature and corrosion. They are used in heat exchangers, boilers, nuclear power generation, and gas turbines, where they resist harsh conditions. They are also employed in chemical processing, petrochemical facilities, and furnace parts, where oxidation and scaling resistance is important. Their capacity to operate in high pressure, temperature variation, and corrosive gas environments qualifies them for applications in high-reliability and long-life systems.
