Yash Fittings, an India-based company with its headquarters in Mumbai, is a renowned exporter and manufacturer of high-quality industrial fittings, renowned for providing guaranteed and high-performance products. Among their specialty products are Super Duplex Steel UNS S32760 Forged Fittings, which are designed to be used in extremely harsh conditions. This grade is a high-end duplex stainless steel with high content of chromium, molybdenum, and tungsten, providing high corrosion resistance, higher strength, and superior durability. Yash Fittings guarantees that these forged fittings adhere to global standards and deliver sustained performance in high-pressure applications.
Specifications : ASTM A182 / ASME SA182
Size: 1/2″NB TO 4″ NB IN
Class : 2000LBS, 3000LBS, 6000LBS, 9000LBS, etc.
Type: Socket Weld (S/W) and SCREWED (SCRD) – NPT, BSP, BSPT, Threaded Fittings.
Super Duplex Steel UNS S32760 Forged Fittings have an impressive blend of chemical, mechanical, and physical properties. Chemically, the alloy contains around 25% chromium, 7% nickel, 3.5% molybdenum, as well as tungsten and nitrogen, giving it superior resistance to pitting, crevice corrosion, and stress corrosion cracking. Mechanically, these fittings provide a tensile strength of approximately 800 MPa and a yield strength of approximately 550 MPa, with exceptional impact toughness even at sub-zero temperatures. Physically, they have good thermal conductivity, minimal thermal expansion, and excellent dimensional stability, so they are compatible with high-temperature, high-pressure conditions.
| UNS | C | Si | Mn | P | S | Cr | Mo | Ni | N |
| S32760 | 0.030 | 0.80 | 1.20 | 0.035 | 0.020 | 24.0/26.0 | 3.0/5.0 | 6.00/8.00 | 0.24/0.32 |
| UNS | Grade | Proof Stress 0.2% (MPa) | Tensile Strength (MPa) | Elongation A5(%) | Hardness Max | |
| HB | HRB | |||||
| S32760 | 2760 | 550 | 795 | 15 | 310 | 32* |
Yash Fittings is a leading supplier of Super Duplex Steel UNS S32760 Fittings in Mumbai, India. We offer an extensive range of Super Duplex Steel UNS S32760 Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Standard | Super Duplex S2760 |
| UNS | S32760 |
| WERKSTOFF NR. | 1.4410 |
Choose Super Duplex Steel UNS S32760 Forged Fittings from Yash Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Super Duplex Steel UNS S32760 forged fittings offer several advantages, including exceptional corrosion resistance to chloride-induced stress corrosion cracking, pitting, and crevice corrosion. Their high tensile strength and excellent toughness make them ideal for use in harsh environments, such as offshore, marine, and chemical industries. These fittings are also highly resistant to erosion, ensuring durability and extended service life. Their ability to perform reliably in extreme temperatures and pressures makes them a preferred choice for critical applications, providing long-term performance and cost-efficiency in demanding industries.
Yes, custom sizes for Super Duplex Steel UNS S32760 Forged Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
| NPS (Normal Pipe Size) | O.D. (Outside Daimeter) | Elbow 90 Deg | Elbow 45 Deg | Return Elbow 180 Deg | ||||
|---|---|---|---|---|---|---|---|---|
| (inch) | Long Radius Elbow | Short Radius | Long Radius Elbow | Long Radius Elbow | ||||
| (millimeter/ MM) | (inch./ Inches) | Center to Face (Inches) | Center to Face (Inches) | Center to Face (Inches) | Radius (Inches) | Center to Center (Inches) | Back to face (Inches) | |
| 1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
| DN (Normal Pipe Size) For ASME B16.9 | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Super Duplex Steel UNS S32760 Forged Fittings find extensive use in industries where strength, corrosion resistance, and reliability are key. They are widely used in offshore oil and gas platforms, marine engineering, desalination facilities, chemical processing units, and power plants. They are suitable for the transportation of aggressive corrosive fluids under high pressure with excellent lifespan and less maintenance. Their high mechanical and anti-corrosive characteristics make them a reliable option for heavy-duty industrial applications requiring high performance in aggressive and harsh environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
