Yash Fittings, based in Mumbai, India, is a reliable maker and exporter of high-performing pipe fittings for various industries with precision-designed solutions. One of its niche products is Nickel Alloy 201 Pipe Fittings, which have superior corrosion resistance, particularly in environments reducing in nature. Nickel 201 is a commercial wrought nickel alloy with low carbon content, suitable for uses such as in caustic alkalis, acids, and in the case of high-temperature applications. These fittings find vast applications in chemical processing, marine, food processing, and electronic industries due to their strength, ductility, and heat stability.
| Specifications | ASTM B366 / ASME SB366, ASTM B366 UNS N02201, ASME SB366 UNS N02201 | |
|---|---|---|
| Ni Alloy 201 Pipe Fittings size | Alloy 201 Seamless Butt Weld Fittings: 1/2″ – 10″ Alloy 201 Welded Butt Weld Fittings: 1/2″ – 48″ | |
| UNS N02201 Pipe Fittings Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504 , BS4504, BS1560, BS10 | |
| Nickel Alloy 201 Fittings Available Thickness | Schedule 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 | |
| ASTM B366 UNS N02201 Buttweld fitting Main Types | Seamless / Welded / Fabricated | |
| ASME SB 564 201 Fittings Thread | NPT , BSPT, BSPP | |
| Nickel Alloy Ni201 Fittings Type | DN15-DN1200 | |
| End | Threaded, Welding, JIC | |
| 2.4068 Nickel Hydraulic Tube Fittings Pressure Rating |
|
|
| Connection | Welding | |
| UNS 2201 Buttweld Fitting Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc | Application |
|
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | ||
Nickel Alloy 201 Pipe Fittings have superior chemical, mechanical, and physical properties, which qualify them for highly corrosive and high-temperature applications. Chemically, Alloy 201 consists of a minimum of 99.6% pure nickel with a low carbon content (0.02% max), which improves its resistance to graphitization and stability at high temperatures. Mechanically, it has good tensile strength (approximately 403 MPa), excellent ductility, and impact resistance, even at sub-zero temperatures. Physically, Alloy 201 possesses a high melting point of about 1446°C, superior thermal and electrical conductivity, and a density of 8.89 g/cm³, which makes it suitable for chemical processing, electronics, and marine use.
| Nickel 201 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| Balance | 0.15 max | – | 0.35 max | 0.35 max | 0.40 max | – | 0.01 max | 0.25 max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
Yash Fittings is a leading supplier of Nickel Alloy 201 Pipe Fittings in Mumbai, India. We offer an extensive range of Nickel Alloy 201 Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Nickel 201 | N02201 | 2.4068 | – | LC-Ni 99 | NW 2201 | NA 12 | НП-2 |
Nickel Alloy 201 Pipe Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Nickel Alloy 201 Pipe Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
