Yash Fittings, Mumbai, India, is one of the leading manufacturers and suppliers of high-quality pipe fittings, known for its excellence and reliability. The company deals in a variety of products, one of which includes Monel 400 Forged Fittings, manufactured from a high-performance nickel-copper alloy. These fittings are popular for their exceptional resistance to corrosion, especially in marine and chemical conditions. With diverse grades, Yash Fittings’ Monel 400 Forged Fittings prove to be superior in terms of durability and best suited for critical industrial use involving high strength and resistance against corrosive chemicals.
Specification : ASTM B564 / ASME SB564
Dimension Standard : ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS.
Socket-weld End – 3000 / 6000/ 9000 LBS.
Monel 400 Forged Fittings are produced from a nickel-copper alloy that has superior chemical, mechanical, and physical characteristics. Chemically, Monel 400 is very resistant to corrosion, especially in seawater and acidic conditions, and so is very well used in marine and chemical applications. Mechanically, it has superior tensile strength and good fatigue properties, providing durability against pressure. Physical-wise, Monel 400 possesses superior thermal and electrical conductivity as well as weldability, which makes it suitable for piping systems used in conditions of extensive temperature changes and exposure to corrosives.
| Grade | Ni | C | Al | Mn | Si | Fe | Cu | S |
| Monel 400 | 63.0 min | 0.3 max | 0.50 max | 2.0 max | 0.5 max | 1.0 – 2.5 | 28.0 – 34.0 | 0.02 max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | Psi – 80,000 , MPa – 550 | 40 % |
Yash Fittings is a leading supplier of Monel 400 Forged Fittings in Mumbai, India. We offer an extensive range of Monel 400 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Monel 400 Forged Fittings offer several advantages, including outstanding corrosion resistance, especially in seawater, acidic, and alkaline environments. They are highly durable, with excellent resistance to pitting, crevice corrosion, and stress corrosion cracking, ensuring reliable performance in harsh conditions. These fittings maintain their strength at elevated temperatures, making them ideal for high-pressure and high-temperature applications. Additionally, Monel 400 offers superior weldability and machinability, allowing for easy customization and installation. With their long-lasting durability and high performance, Monel 400 Forged Fittings are the preferred choice for critical industrial applications.
Yes, custom sizes for Monel 400 Forged Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Monel 400 Forged Fittings are extensively applied in industries that need superior corrosion resistance and high strength. Some typical applications are marine, chemical process plants, oil and gas industries, and pharmaceuticals. Monel 400 Forged Fittings are generally applied in heat exchangers, pressure vessels, pipelines, and reactors, where their corrosion resistance in seawater and acid guarantees long-term durability. Their capacity for withstanding hostile conditions makes them critical in chemical-exposed systems, saltwater environments, and high-temperature applications to provide dependable and effective performance
