Yash Fittings, Mumbai, India, is a leading manufacturer and exporter of high-quality pipe fittings for use in diverse industries like oil and gas, chemical processing, and power generation. Some of the highlighted products include the Low Temperature A350 LF2 Forged Fittings that are produced in conformance with ASTM A350 LF2 grade. These fittings are specifically developed for use in low-temperature conditions and possess good impact resistance and strength at sub-zero temperatures. A350 LF2 fittings possess remarkable strength and are commonly utilized in industries where there are harsh conditions.
| Forged Fittings Specifications | ASTM A350/ ASME SA350 |
|---|---|
| Low Temperature Carbon steel LF2 Forged Fittings size | 1/8” NB to 4” NB (Socket weld & Screwed-Threaded) |
| Low Temperature Carbon steel LF2 Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Low Temperature Carbon steel Gr LF2 Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM A350 Low Temperature Carbon steel LF2 Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Low Temperature Carbon steel LF2 Forged Fittings Thread | NPT, BSPT, BSPP |
| Low Temperature Carbon steel LF2 Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Carbon Gr LF2 Forged Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V |
| A350 LF2 | 0.30 | 0.15–0.30 | 0.60–1.35 | 0.035 | 0.040 | 0.12 | 0.02 | 0.30 | – | 0.08 |
| Grade | Yield Strength, Min (MPa) | Tensile Strength, Min (MPa) | Elongation, min, % |
| A350 LF2 | 250 | 485-655 | 22 |
Low Temperature A350 LF2 Forged Fittings are mainly made up of carbon, manganese, phosphorus, sulfur, and silicon, with minor presence of nickel and chromium. The chemical makeup provides top-class toughness, resistance to brittle fracture, and cold-temperature strength. Mechanically, they have high tensile strength and satisfactory yield strength, providing dependability in tough environments. Physically, the fittings stay ductile and structurally sound even in cryogenic conditions. They also possess good weldability, thus being well suited to use in applications under heavy loads in low temperatures.
| ASTM A350 / A350M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Low Temperature Carbon steel LF2 Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | Low Temperature Carbon steel LF2 fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| Products | Size | |
|---|---|---|
| ASTM A350 Low Temperature Carbon steel LF2 90° Elbow | ASTM A350 Low Temperature Carbon steel LF2 45° Elbow | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| ASTM A350 Low Temperature Carbon steel LF2 Forged Tee | ASTM A350 Low Temperature Carbon steel LF2 Union | |
| ASTM A350 Low Temperature Carbon steel LF2 Forged Cross | ASTM A350 Low Temperature Carbon steel LF2 Insert | |
| ASTM A350 Low Temperature Carbon steel LF2 Screwed Bushing | ASTM A350 Low Temperature Carbon steel LF2 Threaded Pipe Nipple | |
| ASTM A350 Low Temperature Carbon steel LF2 Forged Socket weld Cap | ASTM A350 Low Temperature Carbon steel LF2 Screwed Coupling | |
| ASTM A350 Low Temperature Carbon steel LF2 Forged Plug | ASTM A350 Low Temperature Carbon steel LF2 Street Elbow | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Low Temperature A350 LF2 Forged Fittings offer several advantages, including exceptional toughness and durability in low-temperature environments, ensuring reliable performance in critical applications. Their superior mechanical properties, such as high tensile and yield strength, enhance safety and efficiency under extreme conditions. These fittings provide excellent resistance to impact and corrosion, extending service life even in harsh environments. Precision engineering ensures a perfect fit, reducing the risk of leaks. Widely used in industries like oil and gas, petrochemical, and cryogenics, they ensure robust connections in demanding operations.
Low Temperature A350 LF2 Forged Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Low Temperature A350 LF2 Forged Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Low Temperature A350 LF2 Forged Fittings are typically employed in oil and gas, chemical processing, and cryogenic applications. These fittings are best suited for employment in pipelines, pressure vessels, and reactors under conditions where temperatures drop considerably, like in the case of LNG (liquefied natural gas) plants. Their very low impact resistance at cold temperatures qualifies them for services such as offshore rigs, pipelines in subfreezing climates, and low-temperature storage systems. Such fittings provide safe and assured operation in critical service under severe conditions.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
