Yash Fittings, with head office in Mumbai, India, is a renowned manufacturer and exporter of fine quality pipe fittings catering to the needs of industries belonging to oil & gas, petrochemical, power, and construction sectors. One of their very popular products is the Carbon Steel A105 Forged Fittings intended for high pressure. These forged fittings are manufactured from ASTM A105 grade carbon steel with superior mechanical strength and durability. They are perfect to be used in piping systems where long-term operation with durability, high performance, and cost-effectiveness is essential.
| Forged Fittings Specifications | ASTM A105/ ASME SA105 |
|---|---|
| Carbon Steel A105 Forged Fittings size | 1/8” NB to 4” NB (Socket weld & Screwed-Threaded) |
| Carbon Steel A105 Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Carbon Steel A105 Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM A105 Carbon Steel A105 Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Carbon Steel A105 Forged Fittings Thread | NPT, BSPT, BSPP |
| Carbon Steel A105 Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Carbon A105 Forged Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V |
| A105 | 0.35 | 0.10–0.35 | 0.60–1.05 | 0.035 | 0.040 | 0.12 | 0.40 | 0.30 | 0.40 | 0.08 |
| Grade | Yield Strength, Min (MPa) | Tensile Strength, Min (MPa) | Elongation, min, % |
| A105 | 250 | 485 | 30 |
Carbon Steel A105 Forged Fittings are composed mainly of carbon, manganese, phosphorus, sulfur, and silicon, giving a balanced mix which improves mechanical strength as well as resistance to corrosion. Mechanically, A105 fittings are endowed with high yield and tensile strength, making them ideal for use in high-pressure systems. They have good machinability and weldability. Physically, such fittings show good hardness, impact resistance, and dimensional stability. Their wear resistance and durability qualify them for harsh environments and prolonged service in rigorous applications.
| ASTM A105 / A105M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Carbon Steel A105 Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | Carbon Steel A105 fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| Products | Size | |
|---|---|---|
| ASTM A105 Carbon Steel 90° Elbow | ASTM A105 Carbon Steel 45° Elbow | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| ASTM A105 Carbon Steel Forged Tee | ASTM A105 Carbon Steel Union | |
| ASTM A105 Carbon Steel Forged Cross | ASTM A105 Carbon Steel Insert | |
| ASTM A105 Carbon Steel Screwed Bushing | ASTM A105 Carbon Steel Threaded Pipe Nipple | |
| ASTM A105 Carbon Steel Forged Socket weld Cap | ASTM A105 Carbon Steel Screwed Coupling | |
| ASTM A105 Carbon Steel Forged Plug | ASTM A105 Carbon Steel Street Elbow | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Carbon Steel A105 Forged Fittings offer several advantages, making them ideal for industrial applications. They provide excellent strength and durability, ensuring long service life under high-pressure and high-temperature conditions. Their corrosion resistance makes them suitable for harsh environments, including oil, gas, and chemical industries. With exceptional machinability and weldability, they are easy to install and maintain. These fittings deliver cost-effective performance due to their affordability and extended reliability. Additionally, they comply with international standards, ensuring safety, quality, and compatibility with various piping systems.
Carbon Steel A105 Forged Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Carbon Steel A105 Forged Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Carbon Steel A105 Forged Fittings find widespread applications in industries like oil and gas, petrochemical, power generation, and refineries. They are suitable for high-pressure piping systems like steam, water, oil, and gas distribution lines. They ensure leak-proof, heavy-duty connections in applications where performance and safety come first. They are strong and versatile in nature and thus find applications both above ground and underground, while providing long-term reliability and operational efficiency in adverse industrial conditions.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
