Yash Fittings, an India-based company in Mumbai, is a prominent manufacturer and distributor of superior pipe fittings, known for precision and reliability. Among its wide collection of products, the Alloy 20 Buttweld Fittings are particularly noted for their superior corrosion-resistance, particularly in harsh environments such as sulfuric acid and other acidic chemicals. These fittings, which come in different grades, are well suited for the pharmaceutical, chemical processing, and food processing industries. Yash Fittings’ Alloy 20 Buttweld Fittings provide strong performance and durability, even under demanding situations.
| 20 Pipe Fittings Specifications | ASTM B366/ ASME SB366 |
|---|---|
| Alloy 20 Pipe Fittings size | 20 Seamless Butt Weld Fittings : 1/2″ – 10″ 20 Welded Butt Weld Fittings : 1/2″ – 48″ |
| Alloy 20 Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Alloy 20 Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| 20 Buttweld Pipe FittingsType | DN15-DN1200 |
| ASTM B366 20 Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM B366 Alloy 20 Pipe Fitting |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM B366 20 Buttweld Fitting |
| ASTM B366 20 Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| Alloy 20 Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SA 366 20 Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | Alloy UNS N08020, 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
Alloy 20 Buttweld Fittings are made from a corrosion-resistant high-performance alloy, which is specifically engineered to meet corrosive environments. **Chemically**, Alloy 20 has an optimized composition of chromium, nickel, molybdenum, and copper, providing superior resistance to hydrochloric acid, sulfuric acid, and other aggressive chemicals. **Mechanically**, the fittings have very high tensile strength and superior stress-corrosion cracking resistance, ideal for high-pressure applications. **Physically**, Alloy 20 Buttweld Fittings are strong and resistant to dimensional change, even in high temperatures. They also have excellent pitting and crevice corrosion resistance to provide stable performance over extended periods in sectors such as chemical processing, pharmaceuticals, and food processing. The above characteristics make them suitable for low-maintenance, dependable piping systems in demanding environments.
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
Yash Fittings is a leading supplier of Alloy 20 Buttweld Fittings in Mumbai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
Alloy 20 Buttweld Fittings offer several key advantages, making them ideal for demanding applications. Their exceptional corrosion resistance, particularly to sulfuric acid and other aggressive chemicals, ensures long-lasting durability in harsh environments. Alloy 20 provides excellent mechanical properties, such as high strength, enhanced stress corrosion cracking resistance, and superior weldability. These fittings are highly resistant to pitting and crevice corrosion, making them ideal for industries like chemical processing, pharmaceuticals, and food processing. Their reliability and performance in extreme conditions reduce maintenance costs and extend the lifespan of piping systems.
| Standard Code | Standard Name |
| ANSI ASME SA-366 | Forged Durimet pipe fittings |
| ANSI ASME B16.9 | Factory-Made wrought steel pipe fittings |
| ANSI ASME B16.28 | Wrought steel butt-welding short radius elbows and returns |
| ISO 5251 | Alloy butt-welding fittings |
| MSS SP-43 | Wrought Alloy butt-welding fittings |
| MSS SP-75 | Forging butt-welding fittings |
| German Steel Pipe Fittings Standard | |
| DIN 2605 | Steel butt-welding pipe fittings.elbows and bends |
| DIN 2615 | Steel butt-welding pipe fittings.tees |
| DIN 2616 | Steel butt-welding pipe fittings.reducers |
| DIN 2617 | Steel butt-welding pipe fittings.caps |
| Japanese Steel Pipe Fittings Standard | |
| JIS B2311 | Universal steel butt-welding pipe fittings |
| JIS B2312 | Steel butt-welding pipe fittings |
| JIS B2313 | Steel plate butt-welding pipe fittings |
| Other Steel Pipe Fittings Standard | |
| EN 1025 | 3 Butt-welding pipe fittings |
Yes, custom sizes for Alloy 20 Buttweld Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Alloy 20 Buttweld Fittings are extensively utilized in corrosive environment industries, especially in chemical processing, pharmaceuticals, food and beverage, and petrochemical industries. Their superior resistance to sulfuric acid, hydrochloric acid, and other sour chemicals makes them well-suited for use in heat exchangers, reactors, and piping systems where corrosion resistance is of the highest importance. These fittings are also utilized in marine applications and power plants, offering durability and allowing for reliable fluid flow with structural integrity in high temperature and pressure applications.
