Yash Fittings is a prominent manufacturer and provider of high-strength pipe fittings, providing an extensive product line engineered for diverse industrial purposes. Being experts at making long-lasting and precision-fabricated products, the organization serves industries such as oil and gas, petrochemical, and power generation. Out of their high-end products, Monel 400 Buttweld Fittings are notable for superior corrosion resistance and durability in aggressive environments. Constructed from the Monel 400 alloy, these fittings are well-suited for high-temperature and marine applications, with a Grade of 400 providing superior performance and reliability.
| Specification Properties: | Monel 400 Pipe Fittings |
| Cmmonly Used Fittings Types | End Cap, Stub End, Bend, Tee, Reducer, Cross, Adapter, 4 Wye, Elbow |
| Flange Connection Type | Clamp End / End Bell/ Threaded/ Weld |
| Thickness Tolerance: | Schedule 20S To Schedule XXS |
| Length: | Normal Pipe Size (1⁄₂”) to Normal Pipe Size (48”) |
| Manufacturer Of Fittings Dimension Types: | ANSI B16.28, MSS-SP-43 Type A, JIS B2312, ANSI B16.9, MSS-SP-43 Type B, JIS B2313 |
| Standard Chart : | JIS, NPT, ISO, DIN, EN |
| Pressure Rating Chart : | 150# To 2500#. |
| Materials List: | Bronze, Copper, Iron (Ductile/Cast), Carbon Steel, Inconel, Monel, Hastalloy, Alloy Steel, Brass, Titanium, Chrome-molybdenum, Cupro-Nickel 90/10 & 70/30, Nickel, Nickel Alloys, Tantalum, Stainless Steel. |
Monel 400 Buttweld Fittings consist of a high-performance alloy with a majority content of nickel (approximately 63%) and copper, and traces of iron, manganese, carbon, and silicon. Monel 400 is resistant to corrosion chemically in acidic and seawater environments in particular and is suitable for marine and chemical processing applications. Mechanically, it has good tensile strength and excellent thermal-fatigue strength and fatigue strength for stable performance under pressure. Physically, Monel 400 is stable in temperatures from cryogenic to high temperatures with a high thermal coefficient of expansion, making it robust in varying temperature environments. All these qualities in aggregate make Monel 400 Buttweld Fittings ideal for challenging applications where strength as well as corrosion resistance is significant.
| The Chemical Composition of Monel 400 Pipe Fittings, % | |
|---|---|
| Iron | ≤2.50 |
| Sulfur | ≤0.024 |
| Silicon | ≤0.50 |
| Copper | 28.0-34.0 |
| Nickel | ≥63.0 |
| Carbon | ≤0.30 |
| Manganese | ≤2.0 |
| Tensile Strength, minimum | Yield Strength, minimum | Elongation, minimum | Hardness | ||
|---|---|---|---|---|---|
| Mpa | ksi | Mpa | ksi | % | HB |
| 550 | 80 | 240 | 35 | 40 | 110-150 |
Yash Fittings is a leading supplier of Monel 400 Buttweld Fittings in Mumbai, India. We offer an extensive range of Monel 400 Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Monel 400 Pipe Fittings | N04400 | 2.4360 | NU-30M | NiCu30Fe | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 |
Choose Monel 400 Buttweld Fittings from Yash Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Yes, custom sizes for Monel 400 Buttweld Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Monel 400 Buttweld Fittings find extensive usage in applications requiring materials with superior corrosion resistance and strength. They are used in marine conditions, chemical processing, power plants, and oil and gas operations, where they stand against severe chemicals and seawater. They are also well-suited for high-temperature applications, including heat exchangers, condensers, and boilers. Monel 400’s stress resistance, high pressure, and temperature fluctuation tolerance make it the choice of critical applications in offshore as well as onshore environments.
