Yash Fittings is a leading industrial pipe fittings manufacturer and supplier of high-quality industrial pipe fittings, famous for providing high-quality, corrosion-resistant solutions for industries in bulk. Their specialized products include Hastelloy C22 Pipe Fittings, which are made according to ASTM B366 Grade C22 (UNS N06022). Such fittings provide very high resistance to a wide range of corrosive environments, including powerful oxidizers, acidic solutions, and wet chlorine. Suitable for marine, chemical processing, and pharmaceutical industries, Yash Fittings’ Hastelloy C22 Pipe Fittings provide dependable performance and strength in the most aggressive and extreme service conditions.
Specification : ASTM B366 / ASME SB366
Dimension Standard : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
ASME B16.9 : standard for – Factory-Made Wrought Buttwelding Fittings
ASME B16.25 : Buttwelding Ends
ASME B16.28 : standard for – Butt-Welded Short Radius Elbows & Returns Bends
MSS SP-43 : Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
Size Range : ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
Seamless Butt Weld Fitting Size : 1/2″ – 10″
Welded Butt Weld Fittings Size : 1/2″ – 48″
Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Type : Seamless / Welded / Fabricated
Hastelloy C22 Pipe Fittings contain a high-performance nickel-chromium-molybdenum alloy with iron and tungsten additions. Chemically, the high chromium (20-22.5%) and molybdenum (12.5-14.5%) composition gives excellent resistance to a broad range of corrosive environments, both oxidizing and reducing environments, and the tungsten addition increases its resistance to localized forms of attack such as crevice attack and pitting. Mechanically, Hastelloy C22 provides excellent tensile and yield strength and good ductility. Physically, it has stability over a wide temperature range and good weldability, thermal stability, as well as resistance to stress corrosion cracking, and hence is suitable for severe chemical processing conditions.
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| Alloy C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| STANDARD | UNS | WERKSTOFF NR. | JIS | EN |
| Hastelloy C22 | N06022 | 2.4602 | NW 6022 | NiCr21Mo14W |
Yash Fittings is a leading supplier of Hastelloy C22 Pipe Fittings in Mumbai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Nominal Pipe Size | All Fittings | All Fittings | All Fittings | Elbows/ Tees | 180° Return Bends | 180° Return Bends | 180 Deg Return Bends | Reducers | Caps |
|---|---|---|---|---|---|---|---|---|---|
| NPS | O.D. at Bevel (1), (2) | I.D. at End (1), (3), (4) | Wall Thickness (3) | Centre-to-End Dimension A,B,C,M | Centre-to-Centre O | Back-to-Face K | Alignment of Ends U | Overall Length H | Overall Length E |
| ½ to 2½ | 0.06 -0.03 | 0.03 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 3 to 3 ½ | 0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 4 | 0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 5 to 8 | 0.09 -0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.25 |
| 10 to 18 | 0.16 -0.12 | 0.12 | Not less than 87.5% of nominal thickness | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
| 20 to 24 | 0.25 -0.19 | 0.19 | Not less than 87.5% of nominal thickness | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
| 26 to 30 | 0.25 -0.19 | 0.19 | Not less than 87.5% of nominal thickness | 0.12 | … | … | … | 0.19 | 0.38 |
| 32 to 48 | 0.25 -0.19 | 0.19 | Not less than 87.5% of nominal thickness | 0.19 | … | … | … | 0.19 | 0.38 |
Hastelloy C22 Pipe Fittings from Yash Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Hastelloy C22 Pipe Fittings are available at Yash Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@yashfittings.com
Hastelloy C22 Pipe Fittings are extensively used in those industries that function in highly corrosive and aggressive settings. They are suitable for chemical processing, pharmaceutical manufacturing plants, wastewater treatment, marine, and pollution control systems. These fittings are particularly appropriate for dealing with aggressive oxidizers, acids, chlorine-based chemicals, and mixed chemical streams. Their high resistance to pitting, crevice corrosion, and stress corrosion cracking ensures that they are dependable for use in critical piping systems, reactors, heat exchangers, and scrubbers. Hastelloy C22 fittings provide long-term performance and safety in the most aggressive industrial applications.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
